The Hot Sale Orthopedic Saw And Drill Jacobs Best Price is a versatile surgical system combining high-speed drilling (0–1300 RPM) and precision sawing (15,000 oscillations/min) for orthopedic and trauma surgeries.
ND-5001
ruijin
Powered by a 14.4V lithium-ion battery , it offers 10+ Nm torque and 90+ minutes of runtime , making it ideal for procedures like fracture fixation and joint replacement. Certified by CE and ISO 13485 , this system features a Jacobs chuck compatible with 2–8mm drill bits and Stryker-compatible saw blades .
A one-touch mode selector switches between drill mode and saw mode in <2 seconds . Drill mode offers 0–1300 RPM speed control for screw placement, while saw mode provides 15,000 oscillations/min for rapid bone resection.
The 14.4V battery supports 10+ Nm torque in drill mode and 13,500 cpm in saw mode. Its brushless motor ensures smooth operation and longevity, with ±0.01mm concentricity to minimize bone trauma.
Weighing 1.1 kg with a rubberized grip , the tool reduces fatigue during extended surgeries. All surgical-contact components are autoclavable at 134–138°C , and the sealed electronics protect against steam damage.
The Jacobs chuck supports 2–8mm drill bits from Stryker, Zimmer Biomet, and Smith & Nephew. A tool-free blade release allows quick changes of 6–18mm saw blades in <10 seconds .
Automatic overload protection shuts down the motor if torque exceeds 19 Nm, while thermal cutoff sensors pause operation if internal temperatures exceed 60°C . A low-battery alert activates at 15% charge .
Fracture Fixation: Used in open reduction internal fixation (ORIF) for femoral, tibial, and humeral fractures.
Joint Replacement: Supports acetabular reaming in total hip arthroplasty and femoral canal preparation in knee surgery.
Trauma Surgery: Valuable in mobile trauma units for rapid fracture stabilization, with cordless design enhancing mobility.
Orthopedic Oncology: Enables precise tumor margin resection with minimal healthy tissue loss.
Q: Is the drill compatible with arthroscopic tools?
A: Yes, it includes a 5mm arthroscopic adapter for minimally invasive procedures.
Q: What is the warranty period?
A: The system comes with a 2-year warranty for mechanical components and a 1-year warranty for the battery.
Q: Can it be sterilized with the battery attached?
A: No, the battery must be removed before sterilization. The tool body is autoclavable at 134–138°C .
Q: How is the drill’s accuracy ensured?
A: A ±0.01mm precision motor and anti-vibration housing minimize lateral deviation during drilling.
| Product name | Normal bone drill | Hollow drill | Grinding drill | Craniotomy drill | High torque joint drill |
| Output power(w) | 80-200 | 130 | 130 | 130 | 150-200 |
| Rotating speed(rpm) | 0-1200 | 0-1000 | 0-300 | 0-900 | 0-300 |
| Noise(db) | ≤65 | ≤65 | ≤65 | ≤40 | ≤65 |
| Disinfection(℃) | ≤135 | ≤135 | ≤135 | ≤135 | ≤135 |
| Battery(v) | 14.4 | 14.4 | 14.4 | 14.4 | 14.4 |
| Charging time(h) | 3 | 3 | 3 | 3 | 3 |
