ND-1501（2）
ruijin
The Professional Orthopedic Drill Battery Powered Surgical Precision stands as a cornerstone in modern orthopedic instrumentation, engineered to redefine standards of surgical accuracy and operational reliability across diverse clinical scenarios. Equipped with a high-capacity 14.4V lithium-ion battery , this drill delivers a maximum speed of 1300 RPM and peak torque of 10+ Nm , ensuring consistent performance whether handling delicate pediatric bone structures or dense adult cortical bone. Certified by CE, FDA, and ISO 13485 , it adheres to the strictest global regulatory frameworks, making it a trusted choice for tertiary hospitals, trauma centers, and ambulatory surgical units. Its cordless design eliminates cable restrictions in the operating room, while the ergonomically contoured grip —developed in collaboration with orthopedic surgeons—reduces muscle fatigue during procedures lasting 2+ hours. The drill’s multi-brand compatibility further enhances its utility, seamlessly integrating with existing surgical toolchains to streamline OR workflows.
The 14.4V lithium-ion battery incorporates advanced lithium iron phosphate (LiFePO4) technology , providing 90+ minutes of continuous operation at 800 RPM—sufficient for 3–4 standard fracture fixation procedures. Its smart battery management system includes real-time voltage monitoring and adaptive current regulation, ensuring stable power output even as charge levels drop below 20% to prevent sudden shutdowns during critical steps. The rapid-charging dock restores full capacity in 3 hours , with an LED indicator displaying charge progress (0–100%) to optimize OR scheduling.
Surgeons benefit from stepless speed adjustment ranging from 0–1300 RPM via a responsive thumb dial, allowing for minute calibrations to match tissue density. Torque settings are equally customizable, spanning 2–10+ Nm to accommodate specific surgical needs: 2–4 Nm for delicate hand and wrist surgeries (e.g., carpal tunnel release with bone anchors), 5–7 Nm for long bone diaphysis drilling, and 8–10 Nm for aggressive cortical bone reaming. The drill’s brushless DC motor eliminates commutator wear, ensuring ±0.01mm concentricity and reducing vibration by 40% compared to brushed motor designs, minimizing bone trauma and enhancing precision.
Weighing just 0.95 kg with strategic weight distribution centered at the grip, the drill reduces wrist strain during prolonged use—a critical feature in complex procedures like spinal fusion. Its autoclavable housing withstands repeated sterilization cycles at 134–138°C , with sealed electrical components preventing moisture ingress. The IPX7 waterproof rating allows thorough cleaning under running water, while the titanium alloy chuck ensures secure retention of drill bits even under maximum torque, eliminating slippage risks during high-pressure drilling.
The drill’s universal adapter system supports 2–8mm drill bits, reamers, countersinks, and burrs from leading manufacturers including Stryker, Zimmer Biomet, Smith & Nephew, and DePuy Synthes. This versatility eliminates the need for brand-specific tool inventories, reducing procurement costs by 20%+ in multi-vendor healthcare facilities. A dedicated arthroscopic adapter further extends its utility to minimally invasive procedures, ensuring seamless integration with 3–5mm specialized instruments.
Integrated automatic torque limiting activates at 10.5 Nm to prevent over-drilling and bone breakthrough, while anti-rotation locking secures attachments with a tactile click to avoid intraoperative dislodgment. A dual-alert system—audible beeping and red LED flashing—activates at 15% battery charge , providing ample time for battery replacement without interrupting the surgical flow. The drill also features overheat protection that reduces power output if internal temperatures exceed 55°C , preventing motor damage during extended use.
Fracture Fixation: Indispensable in open reduction internal fixation (ORIF) for femoral, tibial, and humeral fractures, ensuring precise screw placement with ±0.3mm positional accuracy to promote optimal healing.
Joint Replacement: Facilitates acetabular reaming in total hip arthroplasty and femoral canal preparation in knee replacement, with adjustable speed settings matching bone density variations in the proximal femur.
Spinal Surgery: Enables pedicle screw insertion in lumbar and thoracic spine procedures, with torque feedback alerting surgeons to cortical bone engagement for safe screw placement.
Trauma Emergencies: Valuable in mobile trauma units and disaster response scenarios, where its cordless design and robust performance support rapid fracture stabilization in resource-constrained environments.
Pediatric Orthopedics: Gentle speed and torque settings minimize bone damage in procedures like congenital hip dysplasia correction, ensuring safe drilling in underdeveloped skeletal structures.
Q: Is the drill compatible with arthroscopic tools?
A: Yes, it includes a 5mm arthroscopic adapter that enables use with specialized 3–5mm drill bits and burrs, making it suitable for minimally invasive procedures such as rotator cuff repair, ACL reconstruction, and ankle arthroscopy.
Q: What is the warranty period?
A: The drill comes with a 2-year warranty covering mechanical components (motor, chuck, housing) against manufacturing defects, while the lithium-ion battery is covered by a 1-year warranty to ensure consistent performance over time.
Q: Can it be sterilized with the battery attached?
A: No, the battery must be removed before sterilization to protect electrical components. The drill body is fully autoclavable at 134–138°C and can withstand up to 1000 sterilization cycles without performance degradation.
Q: How is the drill’s accuracy ensured during long procedures?
A: Precision is maintained through a combination of a ±0.01mm precision motor , anti-vibration housing that dampens operational oscillations, and a calibrated depth stop collar that allows surgeons to preset drilling depth, ensuring consistent results even during extended use.
| Product name | Normal bone drill | Hollow drill | Grinding drill | Craniotomy drill | High torque joint drill |
| Output power(w) | 80-200 | 130 | 130 | 130 | 150-200 |
| Rotating speed(rpm) | 0-1200 | 0-1000 | 0-300 | 0-900 | 0-300 |
| Noise(db) | ≤65 | ≤65 | ≤65 | ≤40 | ≤65 |
| Disinfection(℃) | ≤135 | ≤135 | ≤135 | ≤135 | ≤135 |
| Battery(v) | 14.4 | 14.4 | 14.4 | 14.4 | 14.4 |
| Charging time(h) | 3 | 3 | 3 | 3 | 3 |
